Threaded Flange Heater Factory

-- Steady & Reliable Manufacturer --

Introduction

Sinton Electric is a precision threaded flange heater factory, manufacturing robust and easy-to-install immersion heaters for a wide range of industrial tanks and pressurized vessels. Our threaded flange heaters combine the powerful, direct heating of an immersion heater with the convenience of a threaded connection, eliminating the need for a separate flange and gasket. Engineered for durability and performance, they are the ideal solution for heating water, oil, chemicals, and other process fluids.

SINCE 2001

Sinton Electric Co.,Ltd.

Sinton Group was created in Yancheng City, Jiangsu Province. Sinton Electric Co., Ltd. is one sub-company of the Sinton group which started its business in 2001, We have formed a comprehensive group with energy-saving heating products as the mainstay, including import and export trade. Sinton's production base is its subsidiary China Hopebond Eco-Tech Co., Ltd., which is a national high-tech enterprise. The self-built 60-mu factory is located in Tinghu Environmental Protection Industrial Park. It has a production plant of 20,000 square meters and an R&D center of 3,600 square meters. It focuses on technological innovation and brand creation. , Specializing in the production of explosion-proof and non-explosion-proof heaters, air duct heaters, pipeline heaters, circulation heaters, electric drying machines, heat-conducting oil furnaces, Electromagnetic coil heaters, and all kinds of electric heating elements, such as direct thermal energy providing element or preheater of project. The products are mainly suitable for high-temperature heating environments of 50-1000℃ and are widely used in environmental protection, medical treatment, coal mining, petroleum, chemical industry, textile, plastics, heating, agriculture, animal husbandry, and other fields, and to promote the development of Zero-Carbon Economy and green earth conversion.

  • Sinton Electric Co.,Ltd.
  • Sinton Electric Co.,Ltd.

Related Products

Threaded Immersion Boiler Heater Threaded Immersion Boiler Heater
Flanged Heaters Flanged Heaters
Flange Immersion Heater Flange Immersion Heater
Flanged Immersion Instrumentt Flanged Immersion Instrumentt
Threaded Cone Connection Thermocouple Threaded Cone Connection Thermocouple
Threaded Type K Thermocouple Threaded Type K Thermocouple
XTFD-50 Electric Industrial Hot Air Duct Heater with Lifting Platform XTFD-50 Electric Industrial Hot Air Duct Heater with Lifting Platform
Thermally Stable Ceramic Strip Heater Thermally Stable Ceramic Strip Heater
Polyimide Film Heaters For 3d Printers Polyimide Film Heaters For 3d Printers

Key Specifications

Parameter Specification / Range
Thread Size 1" NPT to 4" NPT (or BSP)
Heater Element Multiple Tubular Elements Welded to Flange
Sheath Material Copper, Steel, Stainless Steel, Incoloy
Power Range 3kW - 150 kW
Options Thermostat, Thermowell, Drain Valve

Applications

  • Chemical Process Vessels

  • Freeze Protection for Vessels

Our Advantages

  • Easy Installation: The threaded design allows for simple screw-in installation, saving time and labor costs compared to bolted flange heaters that require gaskets and multiple bolts.

  • Leak-Free Design: The heater and flange are a single, welded unit, and the threaded connection provides a secure, leak-free seal when installed correctly with sealant.

  • Customization: We can customize the wattage, voltage, element material, and length of the heating elements to perfectly match your tank and process requirements.

Payment & Shipping

We accept T/T and L/C. We ship globally via sea and air freight. The threaded connections are protected during shipping to prevent damage.

Frequently Asked Questions

  • Q: What is the difference between a threaded flange heater and a standard flange heater?

  • A: A threaded flange heater screws directly into a threaded tank opening. A standard flange heater bolts onto a matching flange on the tank, requiring a gasket. Threaded is simpler; bolted is more common for larger sizes and higher pressures.

  • Q: How do I choose the right thread size?

  • A: The thread size must match the existing opening in your tank. Common sizes are 1.5", 2", and 2.5" NPT. You must also ensure the heater's power is appropriate for the volume of fluid you are heating.

  • Q: Can I use a threaded flange heater on a pressurized vessel?

  • A: Yes, but you must ensure the heater's pressure rating and the pressure rating of the tank connection are compatible with your operating pressure.

  • Q: What is the best way to prevent corrosion?

  • A: Choose the correct sheath material. Use copper for clean water, steel for oil, and stainless steel or Incoloy for corrosive water or chemicals.

  • Q: Can a thermostat be added to a threaded flange heater?

  • A: Yes, we can equip our threaded flange heaters with a built-in, adjustable thermostat for basic temperature control. For more precise control, we recommend using an external controller with a thermocouple.

  • Q: What is a thermowell and should I get one?

  • A: A thermowell is a protective pocket that holds a temperature sensor. We highly recommend adding one so you can accurately measure the fluid temperature and remove the sensor for replacement without draining the tank.

  • Q: Do you offer different thread types like BSP?

  • A: Yes, we can manufacture heaters with NPT (American), BSP (British), or other standard thread types to meet your requirements.

  • Q: How do I size a heater for my tank?

  • A: You need to calculate the required kW based on the volume of fluid, the desired temperature rise, and the heat loss from the tank. Our engineers can assist you with this calculation.
