Thermally Stable Ceramic Strip Heater

A thermally stable ceramic strip heater is composed of a ceramic substrate, a heating element, a ceramic substrate, and a terminal block. Ceramic materials are used because of their high temperature resistance, which can usually work at temperatures up to 1000°C or higher without deformation or failure. The ceramic matrix has excellent thermal conductivity, and the ceramic matrix with high thermal conductivity can quickly Conducts heat to achieve uniform heating. And because of the natural electrical insulation properties of ceramic materials, it ensures the electrical isolation of the heating element from the outside world, providing safety.

Product Parameter

SIZE(MM) WATT(W) SIZE WATT SIZE WATT SIZE WATT
Ø25×25 120 Ø32×25 115 Ø38×25 140 Ø45×25 160
Ø25×30 120 Ø32×30 140 Ø38×30 160 Ø45×30 185
Ø25×32 120 Ø32×32 150 Ø38×32 170 Ø45×32 200
Ø25×35 130 Ø32×35 160 Ø38×35 190 Ø45×35 225
Ø25×38 140 Ø32×38 175 Ø38×38 200 Ø45×38 240
Ø25×40 150 Ø32×40 180 Ø38×40 225 Ø45×40 250
Ø25×45 165 Ø32×45 200 Ø38×45 270 Ø45×45 275
Ø25×50 180 Ø32×50 230 Ø38×50 275 Ø45×50 325
Ø30×25 120 Ø35×25 130 Ø40×25 140 Ø50×25 180
Ø30×30 130 Ø35×30 150 Ø40×30 175 Ø50×30 220
Ø30×32 140 Ø35×32 160 Ø40×32 180 Ø50×32 235
Ø30×35 150 Ø35×35 175 Ø40×35 200 Ø50×35 250
Ø30×38 160 Ø35×38 190 Ø40×38 220 Ø50×38 280
Ø30×40 175 Ø35×40 200 Ø40×40 230 Ø50×40 300
Ø30×45 200 Ø35×45 225 Ø40×45 250 Ø50×45 325
Ø30×50 220 Ø35×50 250 Ø40×50 280 Ø50×50 375
